| • Enjoy smooth online gaming and video streaming with dual band 1200Mbps Wi-Fi • 3 External Antennas Greatly Expand Wireless Coverage • Beamforming technology delivers highly efficient wireless connection (supported by Version 2.0 and above) • Lightning-Fast wired connections using four Gigabit Ethernet Ports • 1 USB Port supports storage and file sharing • Easy setup and management with Tether App |
1200Mbps Wi-Fi for Smooth Entertainment
The Archer C1200 creates a reliable, blazing-fast network using powerful 802.11ac Wi-Fi technology. Now you can enjoy streaming HD video and lag-free online gaming on the clear 5GHz band while using the 2.4GHz band for everyday tasks such as checking email and web browsing.
Easy Setup and Management with the Tether App
The free Tether app is available for both Android and iOS devices, making it easy to set up the Archer C1200 and manage your network settings.
External Antennas Greatly Expand Wireless Coverage
Three external antennas with advanced connection technology allow you to maintain impressive speeds, even over greater distances. This means that you can enjoy incredible wireless coverage and reliability in any part of your large home or office.
Versatile USB Sharing
With the USB 2.0 port, you can share printers, files, and media with numerous devices on your local network or via FTP server from anywhere in the world.
Full Gigabit Wired Connections
With four built-in gigabit Ethernet ports, the Archer C1200 can provide fast, stable connections to all of your favorite wired devices, including game consoles, smart TVs, DVRs, and more.
Guest Network
Provides visitors with Wi-Fi access separate from your main network.
Parental Controls
Manage when and how connected devices can access the Internet.
Advanced Security
WPA/WPA2 encryption creates an active defense against security.
| Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 2400 – 2483,5 MHz, προβλέπει μέγιστη ισχύ εκπομπής τα 100 mW e.i.r.p. Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T. Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017 Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους. |
|
| Προσοχή! Bάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στις ζώνες συχνοτήτων 5150 – 5250MHz και 5250 – 5350MHz προβλέπει μέγιστη ισχύ εκπομπής τα 200 mW e.i.r.p. Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T. Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE Βλ. Π.Δ. 98/2017 Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους. |
| HARDWARE FEATURES | |
| Interface | 4 10/100/1000Mbps LAN Ports 1 10/100/1000Mbps WAN Port 1 USB 2.0 Ports |
| Buttons | WPS/Wi-Fi On/Off Button, Power On/Off Button, Reset Button |
| External Power Supply | 12VDC/1A |
| Dimensions(WxDxH) | 243 x 168 x 33 mm |
| Antennas | 3 external antennas |
| WIRELESS FEATURES | |
| Wireless Standards | IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Frequency | 2.4GHz and 5GHz |
| Signal Rate | 867Mbps at 5GHz, 300Mbps at 2.4GHz |
| Reception Sensitivity | 5GHz: 11a 6Mbps: -92dBm, 11a 54Mbps: -75dBm 11ac HT20: -70dBm, 11ac HT40: -64dBm, 11ac HT80: -62dBm 2.4GHz: 11g 6Mbps: -91dBm, 11g 54Mbps: -75dBm 11n HT20: -73dBm, 11n HT40: -70dBm |
| Transmit Power | CE: FCC: |
| Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security | Enable/Disable SSID Broadcast, 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, QSS, Wireless MAC Filter |
| SOFTWARE FEATURES | |
| Quality of Service | WMM, Bandwidth Control |
| WAN Type | Dynamic IP, Static IP, PPPoE, PPTP(Dual Access), L2TP (Dual Access), Bigpond |
| Management | Access Control, Local Management, Remote Management |
| DHCP | Server, DHCP Client List, Address Reservation |
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | DynDns, NO-IP, TP-Link |
| VPN Server | PPTP, Open VPN |
| Access Control | Parental Controls, Local Management Control, Blacklist, Whitelist |
| Firewall Security | DoS, SPI Firewall, IP and MAC Address Binding |
| Protocols | IPv4, IPv6 |
| USB Sharing | Supports Samba(Storage), FTP Server, Media Server, Printer Server |
| Guest Network | 2.4GHz guest network x 1 5GHz guest network x 1 |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Contents | AC1200 Wireless Dual Band Gigabit Router Archer C1200 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| System Requirements | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Cable or DSL Modem Subscription with an internet service provider (for internet access) |
| Environment | Operating Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
